Description
HDPE Pond Liner is the widely used across a variety of industries including waste containment, water containment, aquaculture, energy, mining, industrial and civil engineering, etc. HDPE Pond Liner is made of top quality high grade polyethylene raw material, adding carbon black, antioxidant, anti-aging and UV-resistance component by the state of the art automatic production lines and advanced pressing technology. HDPE Pond Liner include smooth geosynthetics, Textured Geomembrane HDPE Liner, Composite Geomembrane Liner, etc. HDPE Pond Liner is available in three different colors such as black, white and green. HDPE Pond Liner can be fabricated with single or double-sided surface. ODM, OEM or customization are also available for your project demands.
HDPE Pond Liner is made of 97.5% polyethylene virgin resin, 2.5% carbonblack, antiaging agent, antioxidant,ultraviolet absorber, stabilizer and other additives,by internationally advanced multiple Layer coextrusion blow molding process or multihead flat extrusion process.
HDPE Pond Liner has excellent resistance to chemical acid and alkali, UV resistance, strength,durability and high tear resistance.all products can be produced on ASTM/GRI-GM13 standards.
ASTM 0.5mm 0.75mm 1mm 1.5mm 2.0mm HDPE geomembrane plastic liner fish farm pond liner
Specification
Thickness | 0.75 | 1.0 | 1.25 | 1.50 | 2.00 | 2.50 | 3.00 |
Density g/m2 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 |
Tensile yield strength (N/mm) | ≥11 | ≥15 | ≥18 | ≥22 | ≥29 | ≥37 | ≥44 |
Tensile breaking strength (N/mm) | ≥20 | ≥27 | ≥33 | ≥40 | ≥53 | ≥67 | ≥80 |
Bongation at yield(%) | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 |
Elongation at break(%) | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 |
Tear resistance(N) | ≥93 | ≥125 | ≥160 | ≥190 | ≥250 | ≥315 | ≥375 |
Puncture strength(N) | ≥240 | ≥320 | ≥400 | ≥480 | ≥640 | ≥800 | ≥960 |
Tensile load stress cracking | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 |
Carbon black content(%) | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3. |
Features of Geomembrane
Resistance to Ultraviolet (UV)
High tensile strength
Longer service life standards
Supplied in wide rolls
Good chemical resistance
White surface available by special order
Conductive layer available by special order
