Polyester Geogrid
Polyester warp-knitted geogrid is a geogrid made of high-strength and high-tensile modulus chemical fiber, which is oriented and woven to form a grid fabric, and then coated and processed.
The warp knitted polyester geogrid has high tensile strength, small elongation force, large tear resistance strength, small difference in vertical and horizontal strength, anti-ultraviolet aging, wear resistance, corrosion resistance, light weight, and strong interlocking force with soil or gravel.
Geogrid Applications:
Reinforced steep slopes
Retaining Walls
Sub grade/base reinforcement
Steep Embankments
Vertical WallsLand Field Embankment
Specification
Specification | Unit | 50/50KN | 80/80KN | 100/100KN | 150-150KN | 600-600KN | 800/800KN | |
Tensile Strength | Warp | KN/m | 50 | 80 | 100 | 150 | 600 | 800 |
Weft | Weft | 50 | 80 | 100 | 150 | 600 | 800 | |
Elongation | % | 10 | 10 | 10 | 10 | 10 | 10 | |
Grid Size | mm | 12.7*12.7,25.4*25.4,40*40 | ||||||
Roll Width | m | 1-6 | ||||||
Roll Length | m | 50-200 | ||||||
Package
Our Service:
Free Samples, Customer private labels service, Quality First, Factory Price, Prompt Delivery
