Description
1.High strength, with identical strength of warp and weft when necessary.
2.The woven geotextile undergoes a stabilizing process in production so that it has fair stability and creep behavior.
3.The geotextile has a breadth of 8m such that lapping is reduced and lapping strength in increased.
4.The woven geotextile serves multiple purposes of separation,water discharge and seepage prevention.
5.Competitive advantage. Light weight, High strength, Good integrity, Convenient application, Effectivereinforcement, Low cost.
Application
Used in project of highway, railway, sports ground, dam, water and soil project ,tunnel, Coastal farmland reclamation,mine, environmental protection and coastal tidal land for anti-leakage,filtering,draining,isolating. Also can be made of industry bag, etc.
Package
Width 1m-6m, length 50m-700m (or at request).
Specification
Item | Unit | 25-20KN | 30-20KN | 40-28KN | 60-42KN | 80-56KN | 100-70KN | |
Unit Weight | g/m2 | 136(200lbs) | 150 | 200(315lbs) | 320 | 430 | 550 | |
Tensile Strength | Longitudinal | KN/m | 26.5 | 31.70 | 40.50 | 62.60 | 82.2 | 103.9 |
Transverse | KN/m | 20.6 | 21.00 | 28.20 | 43.00 | 57.2 | 72.4 | |
Elongation | Longitudinal | % | 175 | 18.9 | 18.6 | 18.8 | 19 | 20.8 |
Transverse | % | 151 | 17.8 | 17.8 | 17.8 | 17.9 | 20.9 | |
Grab Tensile Strength | KN | 0.89 | 1.2 | 1.40 | 2.20 | 2.50 | 3.90 | |
CBR Puncture Resistance | KN | 2.5 | 2.8 | 3.60 | 7.40 | 8.50 | 10.20 | |
