Product Details
Fiber glass geogrid is to select high quality enhanced non-alkali fiberglass yarn,and it uses foreign advanced warp knitting woven to become the base materials.Using the warp knitting oriented structure to make full use of the fabric yam strength and improve its mechanical properties ,so it makes good tensile strength ,tearing strength and resistance to creep properties of modified asphalt,and through high quality coating is handled and become planar finely materials.Because of its follow similar compatible principle , the key highlight is composite performance of asphalt mixture .and it fully protects fiberglass base material and significantly improves substrate wearability and shearing ability,thus to strengthen,resist cracking road surface wheel rut etc, ending the diseases occurring highway asphalt pavement hard to solve.
Product Features
1. Light weight, high tensile strength, high modulus, low elongation and good toughness.
2. Corrosion resistance, no long-term creep, long life span.
3. Good physical and chemical stability and good thermal stability.
4. Resistant to fatigue cracking, high-temperature track and low temperature shrinkage cracking.
5. Delaying and decreasing crack reflection.
Specification of Asphalt Reinforcement Fiberglass Geogrid:
Property | TGSB30-30 | TGSB50-50 | TGSB60-60 | TGSB80-80 | TGSB100-100 | |
Ultimate Tensile Strength | MD | 30 | 50 | 60 | 80 | 100 |
CD | 30 | 50 | 60 | 80 | 100 | |
Elongation (%) | MD | 3 | ||||
CD | 3 | |||||
Mesh Size (mm) | 12.7*12.7,25.4*25.4,40*40,etc | |||||
Roll Width (m) | 1-6 | |||||
Roll Length (m) | 50-200 | |||||
Property | TGSB100-100 | TGSB150-150 | TGSB160-160 | TGSB200-200 | |
Ultimate Tensile Strength | MD | 100 | 150 | 160 | 200 |
CD | 100 | 150 | 160 | 200 | |
Elongation (%) | MD | 3 | |||
CD | 3 | ||||
Mesh Size (mm) | 12.7*12.7,25.4*25.4,40*40,etc | ||||
Roll Width (m) | 1-6 | ||||
Roll Length (m) | 50-200 | ||||
Production of Asphalt Reinforcement Fiberglass Geogrid:
Packing & Shipping
Packaging Details: PE films and colored tape. We provide OEM mark.
